The sPod BantamX HD is a compact, solid-state control system that cleans up accessory wiring with a single Ethernet cable into the cab. Its microprocessor-controlled MOSFETs replace traditional fuses and relays, delivering self-healing fault protection from 1.5 to 30 amps per circuit.
Program every switch for dimming, strobe, flash, or linking through the free mobile app, while the machined aluminum HD panel brings RGB backlighting and tactile silicone buttons to your dash.
| Brand | sPod |
| Manufacturer Part Number | BXHDUNI36 |
| Circuits | 8 (expandable) |
| Circuit Rating | 30 amps at 12.5 VDC per circuit |
| Terminal Block | 16-position |
| Controller Ports | 2 (RJ45) |
| Low Voltage Cutoff | Integrated (LVCO) with optional override |
| Fuse | One ATM mini-style fuse for LVCO protection & reset |
| Fault Protection | Failsafe self-healing (from 1.5 to 30 amps) |
| MOSFETs | Current-sensing, controlled by microprocessor (no fuses & relays) |
| In-Line Fuse | 100 amp |
| Battery Cables | Nylon braided, hi-strand crosslinked copper wire with silicone jacket |
| Operating Voltage | 12 VDC or 24 VDC |
| Input Terminal Block | 8-position for controlling outputs |
| Bluetooth | Built-in for remote control |
| Protection | Overheating, over-current, shorts, reverse polarity & field collapse |
| Ignition Control | Safety lock-out for switches 1 and 2 (optional) |
| Software Updates | On-demand wireless |
| Base Material | Powder coated steel with built-in hardware |
| Gasket | Silicone for weatherproofing |
| Lid | Aluminum, thumb screw fastening, with silkscreened outlines for legend placement |
| Mounting | Universal & vehicle specific |
| Insulation | Robust insulated base and cover |
| HD Panel Housing | Aluminum billet machined, powder coated black |
| HD Panel Switches | Tactile switches encapsulated in silicone |
| HD Panel Buttons | Silicone with positive touch feedback |
| HD Panel Dimensions | 2-7/8" W x 4-7/8" L x 1/2" Thick |
| HD Panel Mounting Studs | Two pressed-in 1/4-20 studs x 5/8" long |
| HD Panel Mount | Standard universal articulating mount |
| HD Panel Communication Jack | One standard RJ45 on back |
| HD Panel Cable | 10 ft CAT-6 Ethernet cable included |
| HD Panel Max Distance from Source | 25 ft using standard CAT-6 Ethernet cable |
| HD Panel Bluetooth | Bluetooth LE for programming and control |
| HD Panel Bluetooth Pairing | Three levels of secured or open |
| HD Panel Switch Programmability | Dimming, flash, momentary, strobe, switch linking |
| HD Panel Backlight | All 8 switches backlit, RGB color and intensity adjustable |
| HD Panel Backlight Timer | Adjustable timer to turn off |
| HD Panel Lock-Out | Yes, for safety and security |
| HD Panel Legends | One sheet of 72 legends included |
| HD Panel Status Lights | Red (left) = On, White (center) = Flash/Strobe active, Blue (right) = Active visual feedback |
| HD Panel Status Light Dimming | Yes |
| HD Panel Additional Controllers | Additional HD smart controller can be added |
| HD Panel Compatibility | Can run with Touchscreen, Bluetooth and 8 Switch panel |
| Product Type | Power Management System |
| Form Factor | Solid-State Control Module |
