At 99 dB sensitivity and with 1,000 watt RMS power handling, the PRV Audio 10MR2000-NDY 10" driver is the ideal midrange for use in the highest output audio systems. Designed for natural vocal reproduction and peak SPL, this neodymium powered driver needs just over 5" of mounting depth for installation in systems where space is at a minimum.
Highlights:
- Nominal Impedance: 8 Ohms
- Rated AES Power Handling (RMS): 1000 Watts
- Program Power: 2000 Watts
- Sensitivity (1W/1m): 99 dB
- Voice Coil Diameter: 4″
- Sold individually
General Specifications
- Nominal Diameter: 10" (254 mm)
- Nominal Impedance: 8 Ohms
- Rated AES Power Handling (RMS): 1000 Watts
- Program Power: 2000 Watts
- Sensitivity 2.83V at 1m: 99 dB
- Recommended Hi Pass Crossover: 160 Hz**12dB Per Octave Crossover
- Frequency Response at -10db: 90 -6,500 Hz
- Voice Coil Diameter: 4" (101 mm)
- Voice Coil Wire: Copper
- Voice Coil Winding Depth: 18.8 mm
- Former Material: Glass Fiber
- Magnetic Gap Depth: 9.0 mm
- Frame Material: Die Cast Aluminum
Thiele-Small Parameters
- Equivalent Volume (Vas): 27.98 l
- Excursion (Xmax): 7.15 mm
- Free Air Resonance (Fs): 54.48 Hz
- Mechanical Factor (Qms): 1.54
- Electrical Factor (Qes): 0.21
- Total Factor (Qts): 0.21
- Cone Area (Sd): 373 cm²
- Mechanical Mass (Mms): 59.33 g
- Bl Factor (Bl): 21.73 Tm
- Dc Resistance (Re): 5.0 Ohms
- Inductance (Le): 0.50 mH at 1 kHz
- Mechanical Mass Without Air (Mmd): 35.96 g
- Mechanical Compliance (Cms): 0.143 mm/N
Extra Info
- Overall Diameter: 10.43" (265 mm)
- Front Mount Baffle Cutout: 9.33" (237 mm)
- Mounting Depth: 5.08" (129 mm)
- Overall Depth: 5.49" (139.5 mm)
- Net Weight: 12.78 Lbs (5.8 kg)
- Shipping Weight: 14.55 Lbs (6.6 kg)
