Orion XTR-BP25 Bass Processor with 10V Output & Precision Bass Restoration
Orion XTR-BP25 Bass Processor with 10V Output & Precision Bass Restoration est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Orion XTR-BP25 Bass Processor with 10V Output & Precision Bass ...
Orion XTR-BP25 Bass Processor with 10V Output & Precision Bass Restoration est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Highlight title
Text to highlight a key feature of your product
Description
Description
- XTR Performance Bass Processor: Designed to enhance subwoofer performance by restoring and boosting low-frequency signals.
- Bass Restoration Technology: Recovers bass frequencies lost in compressed music or factory audio systems.
- Sweep Frequency Control: Adjusts the center frequency of the bass enhancement for precise bass tuning.
- Width Bandwidth Control: Allows adjustment of the bass restoration range for deeper bass or tighter punch.
- Selectable Output Voltage: Choose between 2.5V, 5V, 7.5V, or 10V output levels to match amplifier sensitivity.
- High Signal-to-Noise Performance: Provides clean bass enhancement with a signal-to-noise ratio greater than 110dB.
- Ultra-Low Distortion Processing: Maintains high audio fidelity with less than 0.02% total harmonic distortion.
- Balanced / Unbalanced Input Selection: Ensures compatibility with factory radios and aftermarket head units.
- Ground Isolation Control: Helps eliminate alternator noise and system interference.
- Remote Bass Control Support: Allows real-time bass adjustment from the driver’s seat.
- Power Supply: 6.5V – 18V
- Maximum Input Level: 10V
- Maximum Output Level: 10.5V
- Input Sensitivity: 10.5V
- Input Impedance: >50K Ohms
- Output Impedance: 100 Ohms
- EQ Boost / Cut: 15 dB
- Signal-to-Noise Ratio: >110 dB
- THD @ 2V Output: <0.02%
- Channel Separation: >80 dB
- CMRR: -63 dB Balanced / -29 dB Unbalanced
- Frequency Response: 10 Hz – 30 kHz
- Subsonic Filter: 27 Hz – 72 Hz
- Current Draw: 230 mA
- Interchannel Gain Tracking: 0.1 dB
- Fuse Rating: 1A
- Dimensions: 3.98” x 6.42” x 2.09”
