AVID YXZ MT72 72" Front Long Travel Suspension Kit, Billet Race Knuckles
AVID YXZ MT72 72" Front Long Travel Suspension Kit, Billet Race Knuckles - no brakelines / no clamps / no tie rods est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
AVID YXZ MT72 72" Front Long Travel Suspension Kit, Billet Rac...
AVID YXZ MT72 72" Front Long Travel Suspension Kit, Billet Race Knuckles - no brakelines / no clamps / no tie rods est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Highlight title
Text to highlight a key feature of your product
Description
Description
The ultimate race-bred evolution of our proven MTR72 kit. Engineered for aggressive driving, this Race Geometry Edition delivers spot-on KPI, caster, and making all pivots true double shear, while maintaining a true 72” stance. Handcrafted from 4130 Chromoly and TIG-welded, this system eliminates factory weak points and maximizes strength where it matters most.
Key Features
- Race-optimized 72” stance – 4” wider per side with corrected geometry for ultimate stability.
- 4130 Chromoly construction – lightweight, fully TIG-welded durability tested in race conditions.
- 7/8” “stem cup” pivots – signature AVID design for maximum strength.
- 3/4” heim joints – precise camber/caster adjustment with race-ready safety.
- Relocated front shocks – positioned at the correct angle for smoother travel.
- 7/8” uniball bearings – eliminates weak factory ball joints with double-shear race strength.
- 7075-T6 billet uprights – unmatched rigidity and impact resistance.
- 100% bolt-on install – no cutting, welding, or fabrication required.
Performance Specs*
- 3.4” ground clearance at full bump (with stock shocks & 32” tires)
- 23.6” ground clearance at full droop
- 20.2” total wheel travel
- Optional 10” shock tower available
*Actual numbers may vary with tire choice and shock settings.
What’s Included
- Complete front upper & lower control arms (left and right)
- 7075 billet race spindles
- 7075 billet tie-rod kit
- Extended brake lines
- Welded on brake tabs
- All uniballs, rod ends, bushings, and misalignment spacers
- Complete titanium hardware kit
