Viair 200 PSI Fast Fill 2 Gallon Air Source Kit
Viair 200 PSI Fast Fill 2 Gallon Air Source Kit is backordered and will ship as soon as it is back in stock.
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Viair 200 PSI Fast Fill 2 Gallon Air Source Kit
Viair 200 PSI Fast Fill 2 Gallon Air Source Kit is backordered and will ship as soon as it is back in stock.
Highlight title
Text to highlight a key feature of your product
Description
Description
FAST AND FURIOUS.
Need some serious air power without the hassle? Meet the Viair 200 PSI Fast-Fill 2-Gallon Air Source Kit! It’s all-in-one, reliable, and lightning fast. Pre-wired and pre-plumbed for easy installation, it’s perfect for powering your horns, suspension, tires, and inflatables. And it’s a speedy one, filling the 2-gallon tank in 5.5 minutes and recharging from 165-200 PSI in just 1.25 minutes. Plus, it’s easy to install - just connect the pressure switch, make a solid ground, and connect the air line. Let’s get blowing!
- Pre-Installed Pressure Switch
- 1/4" NPT 250 PSI Safety Blow-Off
- 1/4" Drain Cock
- 1/2" NPT Compression Fitting
- Insulated Wiring with Connectors
- Installation Instructions
(Note: Tank mounted air compressors are not fully sealed. For this reason, the manufacturer recommends the tank/compressor system be mounted in the upright position in an enclosed space away from moisture, dirt, debris, etc...)
| PSI | CFM | A | BAR | LPM | A |
|---|---|---|---|---|---|
| 0 | 1.58 | 12 | 0 | 44.7 | 12 |
| 10 | 1.45 | 13 | 1.0 | 38.1 | 13 |
| 20 | 1.22 | 14 | 2.0 | 33.3 | 15 |
| 30 | 1.17 | 15 | 3.0 | 30.6 | 16 |
| 40 | 1.09 | 17 | 4.0 | 29.1 | 17 |
| 50 | 1.06 | 17 | 5.0 | 27.1 | 18 |
| 60 | 1.02 | 17 | 6.0 | 25.3 | 19 |
| 70 | 0.97 | 18 | 7.0 | 24.0 | 20 |
| 80 | 0.92 | 18 | 8.0 | 22.4 | 21 |
| 90 | 0.88 | 19 | 9.0 | 21.0 | 23 |
| 100 | 0.85 | 20 | 10.0 | 19.5 | 21 |
| 110 | 0.81 | 21 | 11.0 | 18.2 | 20 |
| 120 | 0.78 | 22 | 12.0 | 16.7 | 19 |
| 130 | 0.74 | 23 | 13.0 | 15.2 | 19 |
| 140 | 0.71 | 21 | 14.0 | 13.5 | 18 |
| 150 | 0.67 | 20 | |||
| 160 | 0.64 | 20 | |||
| 170 | 0.60 | 19 | |||
| 180 | 0.57 | 19 | |||
| 190 | 0.53 | 19 | |||
| 200 | 0.49 | 18 |
* Supply Voltage: 13.8 Volts
| 2.0 GALLON TANK | FILL RATE |
|---|---|
| 0 to 200 PSI | 5 min. 30 sec. (± 15 sec.) |
| 165 to 200 PSI | 1 min. 25 sec. (± 05 sec.) |
* Supply Voltage: 13.8 Volts
- Viair 380c Air Compressor
- 2 Gallon Viair Air Tank
- 165/200 PSI Pressure Switch
- 150 PSI Safety Valve & Drain Cock
- 1/2" Compression Fitting
| Part Number | MC-238 |
| Manufacturer | Viair |
| Model | 20007 |
| Air Source Kit | |
| Operating Pressure | 200 PSI |
| Unit Length | 19.0″ (482.6 mm) |
| Unit Width | 5.9″ (149.86 mm) |
| Unit Height | 14.2″ (360.68 mm) |
| Tank Volume | 2.0 gal (8.8 L) |
| Voltage | 12 Volts |
| Max Amperage | 16 Amps |
| Max Output | 1.58 CFM |
| Compressor Maximum Duty Cycle | 100% @ 100 PSI |
-
