Amplifier Pride Quattro Plus
In range of Pride Car Audio brand equipment you can find an amplifier Pride Quattro Plus. It is available on the US market now!
It is a 4-channel AB class amplifier, ideal for powering a speakerphone.
Pride Quattro plus Stably operates on a load of 2 ohms per channel, or 4 ohms in the “bridge switching mode” of the channels.
The power of each of the four channels is 100 W for a load of 4 Ohms or 140 W for a load of 2 Ohms, at a voltage of 14.4 volts and K.N.I. 1%
Range of reproduced frequencies, Hz 15 – 30000
RMS rated power of 2 ohms, number of channels x W 4 x 140
RMS rated power of 4 ohms, number of channels x W 4 x 100
RMS rated power at 4 ohms, bridge, W 2 x 280
You can install a quality solution for Your car and connect 4 channel speakers or Twitters. It is possible to work in 2 Ohms.
Buy it now and enjoy the power of sound by Pride Car Audio!
Part number: Q.125PLUS
| Technical feature | |
|---|---|
| 2 Ohm Power | 140 W x 4 |
| 4 Ohm Power | 100 W x 4 |
| 4 Ohm Power Mono | 280 W x 2 |
| Frequency Response | 15 Hz - 30 KHz |
| Signal to Noise | 100 dB |
| Efficiency @ 4ohm | Over 65% |
| Damping Factor | > 200 |
| Input Sensitivity | 8V-0,3V |
| High Pass Filter | 20 Hz - 8 KHz |
| Low Pass Filter | 50 Hz - 8 KHz |
| Strap Connection | No |
| Fuse Rating | 80 A (2 x 40А) |
| Physical feature | |
| Length | 400 mm/15,7" |
| Height | 53 mm/2" |
| Width | 220 mm/8,6" |
| Color | Black |
