Extreme Power and Aggressive Bass Performance
The CMD-5000-G-D4 15-inch SPL subwoofer is built for audio systems that demand maximum bass output, durability, and high-performance engineering. Delivering 5000 watts of maximum power, this subwoofer is designed for high-powered amplifier setups and serious SPL builds.
Its 4-inch four-layer high-temperature voice coil works together with a triple stacked 293 oz magnet motor structure to produce powerful, deep bass with exceptional control. The green die-cast aluminum basket not only gives the subwoofer a bold visual identity but also provides superior structural strength and heat dissipation.
Combined with a dual spider suspension system, polypropylene dust cap, and direct cooling T-yoke design, the CMD-5000-G-D4 is engineered to deliver hard-hitting bass performance while maintaining reliability under extreme power conditions.
If you're building a system designed to move serious air and dominate low frequencies, the CMD-5000-G-D4 is ready.
Why Choose the CMD-5000-G-D4
Massive 5000W Power Handling
Designed for extreme bass systems and high-power amplifiers.
4" High Temperature Voice Coil
Four-layer coil built to withstand aggressive SPL applications.
Triple Stacked 293 oz Magnet Motor
Provides powerful motor force for deep and controlled bass.
Green Die-Cast Aluminum Basket
Strong, lightweight frame that improves cooling and durability.
Direct Cooling T-Yoke System
Allows airflow through the motor to keep the coil cooler under heavy use.
Dual Spider Suspension
Stabilizes the cone for better control during extreme excursion.
Heavy-Duty 4GA Copper Terminals
Reliable connections for high-current amplifier setups.
Specifications
| Specification | Details |
|---|---|
| Model | CMD-5000-G-D4 |
| Speaker Size | 15" Subwoofer |
| Max Power | 5000 Watts |
| Voice Coil | 4" 4-Layer High Temperature |
| Impedance | Dual 4Ω |
| Basket | Green Die-Cast Aluminum |
| Cone | Paper Cone with Foam Surround |
| Dust Cap | Polypropylene |
| Magnet | Triple Stacked 293 oz |
| Cooling | Direct Cooling T-Yoke |
| Suspension | Dual Black Spider |
| Terminals | 4GA Copper Push Terminal |
Built for High-Output Audio Systems
The CMD-5000-G-D4 was designed for audio builders who want serious bass output, competition-ready durability, and professional-level construction.
Whether you're building a demo vehicle, SPL competition system, or powerful daily driver, this subwoofer delivers deep, aggressive bass that commands attention.
Turn up the volume and let the bass take over.
