BANDA ELITE 2000.4 - 1 ohms

With a powerful 2000 Watts RMS in 4 channels and an impedance of 1 Ohm per channel, the amplifiers of the new ELITE line are very versatile, allowing different types of installation with a single amplifier. Thanks to its FULL-RANGE range of frequency response, the ELITE fits into any project with: Subwoofers, Woofers, Mid-Bass, Horns or Super Tweeters, and it is also possible to make connections in 4, 3 or 2 channels, when used in Bridge connections. With the ELITE 2000.4 it is possible to connect a complete medium-sized sound system, enjoying the audio quality already established by BANDA AUDIOPARTS in addition to low consumption.

Technical specifications:

- Max Power 12.6v @ 1 Ohms: 4 x 500 WRMS

- Max Power 12.6v @ 2 Ohms: 4 x 300 WRMS

- Maximum Power 12.6v Bridge @ 2 Ohms: 2 x 1000 WRMS

- Efficiency @ 2 Ohms: 86%

- Efficiency @ 1 Ohm: 80%

- Input Voltage: 9 – 15V

- Input Impedance: 100K Ohms

- THD+N: <1%

- Input Sensitivity: 220mV – 4V

- Signal Noise Ratio: 80dB

- Frequency Response: 5 to 22kHz (-3dBs)

- HPF (Subsonic): 20 to 90Hz @ 12dB/octave Linkwitz-Riley

- LPF (Crossover): 90 to 20kHz @ 12dB/octave Linkwitz-Riley

- Recommended fuse: 100 A

- Resting current: 1 A

- Maximum current (sinusoidal signal): 210 A

- Maximum current (musical signal): 100 A

- Power Cables (recommended min.): 21mm / 4 AWG

- Output Cables (recommended min.): 2 x 2.5mm / 2 x 13 AWG

Dimensions:

- Height (mm): 54

- Width (mm): 209

- Depth (mm): 243

- Weight (Kg): 3.3
